UW.LED75

Underwater LED Light

A high‑efficiency underwater LED delivering 11,000 lumens, wide‑angle illumination, tone‑controlled colour temperature, 6,000 m depth rating in a compact housing.

The Develogic UW.LED75 is a high‑efficiency underwater LED light engineered for deep‑sea imaging, inspection, and illumination tasks. Delivering up to 11,000 lumens with exceptional efficacy of up to 170 lm/W, it provides powerful brightness with minimal energy consumption.

Its Titanium Grade‑5 housing and glass dome ensure reliable operation to 6000 m depth, backed by API 17F pressure testing and certification. The light offers tone‑controlled or fixed‑tone color temperatures, flicker‑free dimming, and both analog and digital control, including RS‑232 for configuration and system integration.

With thermal and overcurrent protection and wide 110° beam angle, it delivers robust, dependable performance for demanding subsea applications.

Key Features

0 lm

Permanent light output (lumens)

0 W

Power consumption (Upto)

0 k

Tone (colour) control (3000k-5700k)

Dimming

Flicker-free dimming

Control

Analog or digital control

Integration

EIA-232 (RS232) for configuration and interfacing

0 m

Depth rating

Mode

Digital controlled pulse mode

0 V

Supply voltage range (9-50V)

High‑efficiency deep‑sea illumination delivering 11,000 lumens, wide‑angle coverage, and precise tone control in a compact, 6000‑metre rated titanium housing.

Power your subsea imaging with a light built for extreme depths. The UW.LED75 delivers 11,000 lumens, exceptional efficiency, and precise tone control in a rugged 6000 m‑rated titanium housing.

Equip your system with reliable, flicker‑free illumination engineered for demanding deep‑sea operations and seamless integration into modern underwater platforms

Request datasheet Request datasheet

FAQs

Interested in this product?

Below you’ll find answers to the questions we’re asked most often. If your query isn’t covered, get in touch and we’ll provide the guidance you need.

Ask a different question Ask a different question

The light is designed for safe operation down to 6000 m, housed in a robust titanium Grade 5 body and pressure tested according to API 17F.

It delivers up to 11,000 lumens with exceptional efficiency—up to 170 lm/W at 50% power and 150 lm/W at full output, measured underwater including dome losses.

Yes. The light is available with fixed 5000 K or tone controlled 3000–5700 K output.

The UW.LED75 supports analog and digital dimming, flicker free operation, and RS 232 (EIA 232) for configuration, system integration, and pulse mode control.

It features thermal and overcurrent protection
